Nuclear Magnetic Resonance Facility

The University of Cincinnati Nuclear Magnetic Resonance (NMR) Facility is located in 409 Old Chemistry. This facility supports the research of faculty and students in the Department of Chemistry, as well as other departments, universities, and industry. The NMR facility offers both solution and solid-state capabilities with its three NMR spectrometers ranging from 9.4 to 11.7 T.  Contact Dr. Alex Greenwood (greenwa2@ucmail.uc.edu, 513-556-9211) for instrument training, experiment scheduling, or more information.

Instrumentation

Bruker NEO 400

Bruker NEO 400

Bruker NEO 400 (409 Old Chemistry)

Magnet: Bruker Ascend 9.4 T, 54 mm (narrow) bore, BOSS-3 36 shim system

Console: Bruker NEO 400, two rf channels, BLABBH500/100 2-channel amplifier system, HPPR II preamplifier unit

Probes:

Bruker 4mm solid-state MAS HX iProbe, 109Ag-19F observe with 1H decoupling and observe, up to 15 kHz spinning, automatic tuning and matching accessory, VT range from -80 to 200 C (PI MAS-400-S1-4.0mm BB/F-H)

Bruker 5 mm SMART 109Ag-31P and 19F observe with 1H decoupling and observe, Z-axis PFG, automatic tuning and matching accessory, VT range from 150 to +150 °C (PI HR-400-S1-BBF/H/D-5.0-Z SP)

Bruker 5 mm Quattro Nucleus (QNP) 31P/13C/15N and 1H, Z-axis PFG (PH QNP 400S1 P/C/N-H-D-05 Z)

Computer: HP z440 running TopSpin 4.5.0 in CentOS 7.5.

Accessories: SampleXpress Lite autosampler (16 sample positions), BCU I VT control unit

Bruker AV 400

Bruker AV 400

Bruker AV 400 (409 Old Chemistry)

Magnet: Bruker Ultrashield 9.4 T, 54 mm (narrow) bore, BOSS-1 20 shim system

Console: Bruker Avance I 400, two rf channels, BLA2BB150/60 2-channel amplifier system, HPPR preamplifier unit

Probes:

Bruker 5 mm 109Ag-31P and 19F observe with 1H decoupling and observe, Z-axis PFG, automatic tuning and matching accessory, VT range from -150 to +150 °C (PA BBO 400S1 BBF-H-D-05 Z)

Bruker 5 mm Inverse 109Ag-31P decoupling and observe with 1H decoupling and observe, Z-axis PFG, VT range from -150 to +150 °C (PH BBI 400S1 H-B-D-05 Z)

Computer: HP Z4 G4 running ICON-NMR/Topspin 2.1PL8 in CentOS 7.6

Accessories: SampleXpress Lite autosampler (16 sample positions)

Bruker HD 500

Bruker HD 500

Bruker AVIII HD 500 (409 Old Chemistry)

Magnet: Bruker Spectrospin 11.7 T, 54 mm (narrow) bore, BOSS-3 36 shim system

Console: Bruker AVIIIHD 500, two rf channels, BLAXH2H300/100/150 + BLAX300 3-channel amplifier system, HPPR/2 preamplifier unit

Probes: Bruker 5 mm 109Ag-31P observe with 1H decoupling and observe, Z-axis PFG, automatic tuning and matching accessory, VT capabilities (BBO 500S2 BB-H-D-05 Z)

Bruker 5 mm Inverse 109Ag-31P decoupling and observe with 1H decoupling and observe, Z-axis PFG (PH BBI 500S2 H-BB-Z-05 Z)

Bruker 5 mM Inverse Triple resonance (TXI) 1H-13C/15N, Z-axis PFG

Computer: HP Z4 G4 running ICON-NMR/Topspin 3.8 in Alma Linux 9.6

Accessories: SampleXpress Lite autosampler (16 sample positions), BCU I VT control unit

People

Alex Greenwood, Manager
(greenwa2@ucmail.uc.edu, 513-556-9211)

Dr. Alex Greenwood serves as the manager of the UC NMR facility. Alex has a broad background in NMR spectroscopy, with experience in proteins, peptides, and small molecules in solution and in the solid state both using magic-angle spinning (MAS) and oriented-sample (OS) approaches. His more recent academic contributions include applying density functional theory (DFT)-based chemical shift calculations to solid-state NMR-based structure calculations of both proteins and pharmaceuticals.

Rates

University of Cincinnati ($/hr)
Instrument 1-8 hr
 8-24 hr
 24+ hr
NEO 400 $6.00 $5.00 $3.00
AV 400      $6.00 $5.00 $3.00
HD 500 $6.00 $5.00 $3.00
External ($/hr)
Instrument
Academic Industry
NEO 400 $10.00 $50.00
AV 400      $10.00 $50.00
HD 500 $10.00 $50.00
